Type: Pelagic stern trawler
Built: 1981 Ireland, Killybegs
Conversions: 1986: lengthened 7.5 m in Denmark, stern deck raised
1990: new wheelhouse and deck house, incl. skipper cabin
1991: forecastle fitted
1994: stern lengthened by 2 m and mid-ship lengthened by 4 m
1997: In connection with reflag into Sweden the whole accommodation was renewed., galley + other upgrading
2001 New main engine and gear box and nozzle
Class: Sjöfartsverket
Class Status: Renewal term survey
Tailshaft due
Tailshaft
Tonnage: 482 GT
Dimensions: Loa 43.30 x Beam 8.15 x Depth 4.02 m

Main engine:

2200 BHP Wärtsilä - new 2001, Major overhaul 2006
Propeller: 2400 mm in nozzle,30 ts bollard pull, 225 rpm on propeller, - all new 2001
Hytek front gear, overhauled -01
Side Thrusters: 1 x bow thruster abt. 100 hp, make Brunvoll
Aux. engines:

1 x Volvo 300 hp, new 2005
1 x 585 kw Mitsubishi (fitted 2004)
1 x Habour gen. set, new 1995, make Perkins 60 HP fitted forward
Generators: 1 x 270 kVA, new 2005
1 x 675 kVA gen.
New switch board 2005

Deck equipment:

1 x MMC vacuum pump new 1993 14 inch pipes out and 12 inch pipes "in"
2 x 14/16 ts Brattvaag split trawl winches, new motors fitted 1994 (14 ts on port winch, 16 ts on SB winch)
Winches fitted Syncro 1000 trawl system (never used by present owner)
Winches carry abt. 800 fathoms of 22 mm wire each
1 x net drum fitted aft, new motor 12/95 - this drum refitted 2002.
1 x net drum new 2002, 35 ts, high pressure "Hägglund".
1 x 16 ts top line winch mid-ship in front of wheelhouse
1 x Atlas crane aft (type 3006) new 1995, with 28" power bloc
1 x Hiab Sea crane (1999)
1 x net sounder winch
1 x anchor winch, new chain/anchor 1995
1 x tail line winch
Tenfjord steering gear 2001
1 x Karmøy fish pump, 1500 46.18 type
1 x Rapp fish pump, new 2000
1993 new hydr. station for winches
1994 new winch pumps in engine room
1 x net drum extra to be fitted 572002

Freezing equipment:

2 x RSW plants (one new 1994 fitted in forward lower hold, one fitted on main deck)
1 x 160,000 kcal/hr with 61 HP Grasso compressor, type PC 69
1 x 350,000 kcal/hr with Promac compressor
Hold capacity: 510 m3 in 6 x RSW tanks tanks) + forward Hold abt. 80 m3 - where RSW plant fitted at present.
Bunkers: 15 ts fresh water
70 ts fuel

Electronics:

1 x Transas Plotter (1997)
2 x JRC 250 98
1 x Racal Decca Bridge Master radar Furuno 2115
1 x Skipper, 2001
1 x Kaijo Denki KCH 1827 color scanning sonar
1 x Sodena, 19991 AIS
1 x telex
1 x Skanti 8000, radio receiver
1 x Sailor new 2005
1 x watt radio transmitter
2 x Compac SP VHFs
2 x Compac SP VHFs
2 x Furuno GPS
1 x Furuno D GPS
1 x Shipmate RS 40001 x Robertson gyro
1 x fax
1 x Robertson autopilot

Accommodation: For 10 men in 5 x 2 cabins
Various: Speed: 12,5 knots on 225 litres/hrs
Desmi ballast pumps
Electric heating in vessel
Electrich hot water production for domestic water
Hytek from end gear box for hydraulics, compl. renovated 2001
1 x Alpha Laval fuel separator, new 2000
1 x hydr. pump station forward in vessel for trawl adjustments while trawlin
Vessel has been sandblasted and zinc coated summer 1999 in Skagen - all outside and all RSW tanks

Price: Euro 1 600 000 excluded fishing licenses
